Constant Voltage 160lm/W High Efficiency Flexible Strips CE DC24V smd2835 Led Strip lights for linear lighting system

We Newstar's High efficiency smd2835 strips constant voltage circuit design to realize 160lm/w led strip lights, to achieving high lumen efficiency requirements. Newstar's smd 2835 LED strips series is high brightness LED Strips, reach 24~26lm each LED, our SMD2835 Flexible Strips has over 80 to 90 in its CRI, and 90RA 95RA or more than 97RA are also available.

High Efficiency 160lm/w 2835smd constant current 64leds/m led strip lights

Technical Parameters

• Product Name: High Efficiency 160lm/w smd2835 constant voltage 64leds/m led strip lights
• Model No: NSS-2835-64
• Led Type: SMD2835
• Led Quantity: 64Leds/M
• Lumen/Meter: 1560-1640lm/Meter
• Actual Power(w/m): 9.6W/Meter
• CRI(Ra): >80
• Luminous Efficiency: >160Lm/W
• PCB Width: 10mm
• Voltage: DC24V
• Cuttable size: 125mm/24v
• Color: Warm white/Natural white/Cool white
• CCT(K): 2700K~6000K
• IP Grade: IP65/IP67/IP68
• Beam Angle: 120°
• Ambient Temperature: -25℃ ~ +45℃
• Warranty: 5-year or 30000hr whichever comes first
• Length: 5Meter/Roll

High Efficiency 160lm/w smd2835smd constant voltage 80leds/m led strip lights

Technical Parameters

• Product Name: High Efficiency 160lm/w smd2835 constant voltage 80leds/m led strip lights
• Model No: NSS-2835-80
• Led Type: SMD2835
• Led Quantity: 80Leds/M
• Lumen/Meter: 1950-2050lm/Meter
• Actual Power (w/m): 12W/Meter
• CRI(Ra): >80
• Luminous Efficiency: >160Lm/W
• PCB Width: 10mm
• Voltage: DC24V
• Cuttable size: 100mm/24v
• Color: Warm white/Natural white/Cool white
• CCT(K): 2700K~6000K
• IP Grade: IP65/IP67/IP68
• Beam Angle: 120°
• Ambient Temperature: -25℃ ~ +45℃
• Warranty: 5-year or 30000hr whichever comes first
• Length: 5Meter/Roll

High Efficiency 160lm/w smd2835 constant voltage 128leds/m led strip lights

Technical Parameters

• Product Name: High Efficiency 160lm/w smd2835 constant voltage 128leds/m led strip lights
• Model No: NSS-2835-128
• Led Type: SMD2835
• Led Quantity: 128Leds/M
• Lumen/Meter: 2850-3000lm/Meter
• Actual Power(w/m): 18W/Meter
• CRI(Ra): >80
• Luminous Efficiency: >160Lm/W
• PCB Width: 12mm
• Voltage: DC24V
• Cuttable size: 62.5mm/24v
• Color: Warm white/Natural white/Cool white
• CCT(K): 2700K~6000K
• IP Grade: IP65/IP67/IP68
• Beam Angle: 120°
• Ambient Temperature: -25℃ ~ +45℃
• Warranty: 5-year or 30000hr whichever comes first
• Length: 5Meter/Roll

High Efficiency 160lm/w smd2835 constant voltage 160leds/m led strip lights

Technical Parameters

• Product Name: High Efficiency 160lm/w smd2835 constant voltage 160leds/m led strip lights
• Model No: NSS-2835-160
• Led Type: SMD2835
• Led Quantity: 160Leds/M
• Lumen/Meter: 3350-3500lm/Meter
• Actual Power (w/m): 21W/Meter
• CRI(Ra): >80
• Luminous Efficiency: >160Lm/W
• PCB Width: 12mm
• Voltage: DC24V
• Cuttable size: 50mm/24v
• Color: Warm white/Natural white/Cool white
• CCT(K): 2700K~6000K
• IP Grade: IP65/IP67/IP68
• Beam Angle: 120°
• Ambient Temperature: -25℃ ~ +45℃
• Warranty: 5-year or 30000hr whichever comes first
• Length: 5Meter/Roll

Newstar LED Co., Limited Established in 2009, covering an area of 2100 square meters, we now have over 50 employees, we are a professional manufacturer and exporter that is concerned with the design, development and production of LED lighting products. We are located in Shenzhen city, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

Newstar has a well-trained team including full experienced technicians and salesman, "product quality and service foremost" is our main goal. An annual sales figure that exceeds USD15,000,000 and 80% of our products exported to more than 100 countries. More and more customers are continually choosing Newstar for our excellent quality and service, your OEM or ODM are welcomed

The main products of our company: led flood light, led high bay light, led panel, led strip, led downlight, led tube, and so on, all of which are widely used in commercial lighting decoration, indoor and outdoor using, home and decoration, bus and train station using, advertising and cabinet Lighting.

Quality Control: Newstar’s operation strictly follows the ISO9001 standard. All of our products have CE, ROHS certificates. The key material we source from Samsung, Cree, Bridgelux, Epistar, MeanWell to assure a steady and top-grade quality.

As a globally operating manufacturers, we also strongly encourage socially and environmentally authoritative energy-saving policies around the world - as well as sponsoring art and beauty at home and world! Join us to achieve the mutual benefit, and let's make people's life brighter and more colorful!
